& Son was a German company, located in Kassel, best known during the 20th century as a maker of transportation equipment, including locomotives, trucks, buses and trolleybuses, and armoured fighting vehicles and weapons. |
The development of the unit-Trucks began in 1934. Originally it was planned to develop vehicles with 2 (1.5 t), 3 (2.5 t) and 4 (4t) axes. In the end, it was only the three-axle truck with 2.5 t payload, produced in series, the officially as a lightweight all-terrain trucks, open referred to. He was rather under the concepts of unit Truck or unit-Diesel known. Of the 4 axes of at least 4 prototypes were made. These were later converted to a floating 8-wheel vehicles with different Rustsatzen and tested. A leader in the development of the vehicle frame was Henschel . The 80-HP diesel engine was made by YOU in collaboration with Henschel and Humboldt-Deutz Motoren AG developed. The power was a commercially available four-speed gearbox and a two-stage intermediate gears with lockable differential gear, headed to all three axes. 8 Translations were available. Each axis had another, self-locking differential gear. Each of the 6 driven wheels had suspension single and single tyres. All of this gave the unit a diesel above-average off-road capability. | ![]() |
