Titan spezialfahrzeuge GmbH is a manufacturer of heavy-duty vehicles and special vehicles.
In addition, Titan builds oversized Heavy-duty trucks and oilfield vehicles for special operations, in particular in the Oilfield in Africa and the Arab world, where the streets, and the restrictions for the dimensions, axle loads and Weights must be adhered to when wells will be transported along dirt tracks. The Oilfield truck Titan Z 80 to 600 F 8x8 with 350 cm width, with an unladen weight of 30 tonnes of total permissible weight up to 80 tons and can pull up to 500 tons. The heavy-duty tractor Titan Z 64 600 F 8x8 empty weight of 22.5 tonnes, and can carry 42 tons of trailer load and up to 1000 tons. These vehicles are Mercedes Actros-cabs and engines installed, as well as the axes of Kessler + co., with tyres in the Format of 29.5 R 25. The function of the cooling is guaranteed up to 50 °C, in particular in the case of the variants with engine under a long hood in front of the Cab.
Also for the airfield fire trucks such as Rosenbauer Simba 8x8 HRET builds titanium chassis. Two uprated Mercedes-Benz Actros-V8-engines of the Titan Chassis T52-1400 8x8 are two , Allison Transmission 4800 SP torque Converter transmission with Retarder coupled to and driving four axles from Kessler. In accordance with international regulations, such an airfield fire-fighting vehicle needs to accelerate, in under 21 seconds, to 80 km/h. In the up to 52 tonne Simba achieve this, the total of 1400 HP engines that enable a maximum speed of 135 km/h.
TITAN Spezialfahrzeugbau GmbH is one of the leading manufacturers for Heavy-Duty and Special purpose vehicles. We develop and assemble vehicles for heavy duty transport, special operations on oil fields and Mines as well as customized vehicles according to customers’ requirements. Since 1994, the TITAN Spezialfahrzeugbau GmbH is based in Backnang/Sulzbach.
TITAN Heavy duty tractors, vehicles and tracks:
Z 52 609 F 6x6
Z 64 600 F 8x8
Z 72 540 F 6x6 / Z 80 609 F 6x6
Z 72 540 H 6x6 / Z 80 609 H 6x6
Actros 6 x 6
Actros 8 x 8
Chassis TITAN T52-1300 8x8
|
 |
